PFPE AF Coating material
FCL Series

HYDROPHOBIC COATING MATERIAL(DILUTED)

· Fluorinated Organic Compound modified to unique structure

· Providing Anti-fouling, Anti-fingerprint feature on substrate surface

· Anti-smudge, easy clean surface formation

· Thin layer preserving substrate's optical property

· Excellent wear resistance and slippery

· PFOA, PFOS free



Appearance

Clear, Transparent liquid

Solid ingredient content

0.05-0.2wt%

Solvent

Fluorinated Organic Material

Layer thickness

10~30nm





Substrate

Touch screen panel, Cover glass
PC LENS, Plastic film, various metal surface

Coating method

Dipping, Spraying





Anti-Scratch Test
Steel Wool #0000, 1kg, 10x10mm, 40mm, 40rpm


Test Type

Condition



Water contact angle

1~2mm diameter water drop

>117°

Durability

Eraser, 8,000 repeat rubbing

>100°

Friction coefficient

A4, CoF detector

<0.03

oil repellency

Oil-based pen

Excellent

UV

Sunlight

Good



Test Type

Condition



Water contact angle

1~2mm diameter water drop

>110°

Durability

Eraser, 5,000 repeat rubbing

>100°

Friction coefficient

A4, CoF detector

<0.05

oil repellency

Oil-based pen

Good

UV

Sunlight

Good


Test Type

Condition



Water contact angle

1~2mm diameter water drop

>107°

Durability

Eraser, 5,000 repeat rubbing

>100°

Friction coefficient

A4, CoF detector

<0.08

oil repellency

Oil-based pen

Good

UV

Sunlight

Good
