PFPE AF Coating agent
NC Series
HYDROPHOBIC COATING AGENT(UNDILUTED)
· Fluorinated Organic Compound modified to unique structure
· Providing Anti-fouling, Anti-fingerprint feature on substrate surface
· Anti-smudge, easy clean surface formation
· Thin layer preserving substrate's optical property
· Excellent wear resistance and slippery
· PFOA, PFOS free
|
|
|
|
|
|
Appearance
|
Clear, Transparent liquid
|
|
Active content
|
20wt%
|
|
Solvent
|
Fluorinated Organic Material
|
|
Layer thickness
|
10~30nm
|
|
|
|
|
Substrate
|
Touch screen panel, Cover glass,
PC LENS, Plastic film, various metal surface
|
|
Coating method
|
Dipping, sputtering, Spraying
|
|
|
|
Vacuum Deposition on Gorilla Glass #3 with SiO2 100Å
|
Product Name
|
Contact Angle(water)
|
Oil Repellency
|
Anti-Scratch Test
|
Anti-Abrasion Test
|
Coefficient of Friction
|
|
NC2100
|
112°
|
Great
|
≥110° at 3,000 Cy.
|
Good Oil repellency at 3,000 Cy.
|
0.04
|
|
NC800
|
107°
|
Good
|
≥90° at 3,000 Cy.
|
Good Oil repellency at 2,000 Cy.
|
0.04
|
|
NC600
|
107°
|
Good
|
≥105° at 3,000 Cy.
|
Good Oil repellency at 2,000 Cy.
|
0.06
|
Spray 1/250 Diluted Solution on Gorilla Glass #3 after Plasma Treatment
|
Product Name
|
Contact Angle(water)
|
Oil Repellency
|
Anti-Scratch Test
|
Anti-Abrasion Test
|
Coefficient of Friction
|
|
NC2100
|
112°
|
Great
|
≥110° at 3,000 Cy.
|
Good Oil repellency at 3,000 Cy.
|
0.04
|
|
NC600
|
107°
|
Good
|
≥105° at 3,000 Cy.
|
Good Oil repellency at 2,000 Cy.
|
0.06
|
|
|
|
- Anti-Scratch Test
Steel Wool #0000, 1kg, 10x10mm, 40mm, 40rpm
- Anti-Abrasion Test
6mm Dia, 81A, 1kg, 10x10mm, 20mm, 40rpm
|
|
|
|
|
|
|
|
|
|
